AquaDam Specifications

AquaDam Specifications

Inflated
Dimensions
Controllable
Mud/Water
Depth*
Specifications
of Inner and
Outer Tubes
Capacity**
per linear ft
Dry Weight
per linear ft
1' H x 2' W
(0.3m tall)
9”
(23 cm)
Inner Tubing:
1 ply, 12 mil

Polyethylene
Outer Sleeve: 1 ply,
300 lb/in² burst
strength PP
12 gal/LF
45 liters/LF
0.75 lbs/LF
0.34 kg/LF
1.5' H x 3' W
(0.45m tall)
14”
(36 cm)
Inner Tubing:
1 ply, 12 mil

Polyethylene
Outer Sleeve: 1 ply,
300 lb/in² burst
strength PP
25 gal/LF
95 liters/LF
0.95 lbs/LF
0.43 kg/LF
2' H x 4' W
(0.61m high)
18”
(45cm)
Inner Tubing:
1 ply, 12 mil

Polyethylene
Outer Sleeve: 1 ply,
300 lb/in² burst
strength PP
50 gal/LF
189 liters/LF
1.5 lbs/LF
0.68 kg/LF
2.5' H x 5' W
(0.76m tall)
24”
(61 cm)
Inner Tubing:
1 ply, 12 mil

Polyethylene
Outer Sleeve: 1 ply,
300 lb/in² burst
strength PP
88 gal/LF
333 liters/LF
1.85 lbs/LF
0.84 kg/LF
3' H x 7' W
(0.9m tall)
30”
(77 cm)
Inner Tubing:
1 ply, 12 mil

Polyethylene
Outer Sleeve: 1 ply,
300 lb/in² burst
strength PP
120 gal/LF
454 liters/LF
2.5 lbs/LF
1.1 kg/LF
4' H x 9' W
(1.2m tall)
38”
(97 cm)
Inner Tubing:
1 ply, 12 mil

Polyethylene
Outer Sleeve: 1 ply,
300 lb/in² burst
strength PP
210 gal/LF
795 liters/LF
4.3 lbs/LF
1.9 kg/LF
5' H x 11' W
(1.5m tall)
44”
(112 cm)
Inner Tubing:
1 ply, 12 mil

Polyethylene
Outer Sleeve: 2 plys,
300 lb/in² burst
strength PP
320 gal/LF
1,211 liters/LF
6.4 lbs/LF
2.9 kg/LF
6' H x 13' W
(1.8m tall)
54”
(137 cm)
Inner Tubing:
1 ply, 12 mil

Polyethylene
Outer Sleeve: 2 plys,
300 lb/in² burst
strength PP
450 gal/LF
1,703 liters/LF
8.5 lbs/LF
3.9 kg/LF
8' H x 17' W
(2.4m tall)
74”
(188 cm)
Inner Tubing:
1 ply, 12 mil

Polyethylene
Outer Sleeve: 2 plys,
300 lb/in² burst
strength PP
700 gal/LF
2,650 liters/LF
12 lbs/LF
5.4 kg/LF
10' H x 21' W
(3m tall)
88”
(223 cm)
Inner Tubing:
2 plys, 8 mil

Polyethylene
Shroud: 1 PP woven
shroud around both
inner tubes

Outer Sleeve: 4 plys
of 300 lb/in² burst
strength PP
1,000 gal/LF
3,785 liters/LF
25 lbs/LF
11.3 kg/LF
12' H x 25' W
(3.7m tall)
100”
(254 cm)
Inner Tubing:
2 plys, 8 mil

Polyethylene
Shroud: 1 PP woven
shroud around each
inner tube.

Outer Sleeve: 5 plys
of 300 lb/in² burst
strength PP
1,700 gal/LF
6,435 liters/LF
35 lbs/LF
15.9 kg/LF
16' H x 33' W
(4.8m tall)
126”
(320 cm)
Inner Tubing:
3 plys, 5 mil

Polyethylene
Shroud: 2 PP woven
shrouds between
inside tubes

Outer Sleeve: 7-plys
of 300 lb/in² burst
strength PP
3,000 gal/LF
11,356 liters/LF
51 lbs/LF
23 kg/LF

*This number is based on the friction of a rocky bottom. Slick mud, poly pond liners, and other slick surfaces may require the use of a taller primary
AquaDam and/or a support dam installed behind the primary AquaDam.
** Capacity is based on installation on flat ground. Slopes will reduce internal volume of AquaDam.

Aqua Dam Inc
“Water Controlling Water”
www.aquadam.net
1.800.682.9283
+1.707.764.1999
matthew@aquadam.net
Revised 2/2018
